200A Intelligent IGBT engine welder with VRD
The MMA inverter IGBT welder is a new design intelligent arc welding machine. It has self diagnosis and multiple self-protection functions of CPU control system. Fast system response ensures the whole
The MMA inverter IGBT welder is a new design intelligent arc welding machine. It has self diagnosis and multiple self-protection functions of CPU control system. Fast system response ensures the whole welder to work reliably and stably. Very small leakage control, let the efficiency loss close to zero. Accurate current output, the welder can be widely used in all kinds of acid and alkaline electrode welding. It has the advantages of easy arc striking, small spatter, stable output current and good welding forming. Automatic hot arc striking function. With the function of automatic voltage compensation, high load duration, long-term welding. Adaptive thrust current mode. Improve the performance when welding the extension line. It also has the self checking function when the welder goes something wrong and show the fault code on the screen. It help you repair the welding machine easer.
Main technical parameters: Name: Engine Welder KTWG200A MMA welder: Input voltage frequency: 220V / 50Hz or 60Hz Rated no-load voltage (V): 67.5-68DC Welding Voltage: 27.6DC Rated welding current (a): 190A Rated input power (KVA): 5.3 Applicable voltage range: 220-380v single phase Display: LED screen Applicable output line length: less than 20 m standard length. Suitable electrode: J421, J422, J506, J507 Applicable Electrode (mm): 1.6-4.0 Continuous load rate: 60% Efficiency: 90% Power factor: 0.9 Protection function: Low voltage, over voltage, over temperature, over current. VRD. Protection grade: IP21S Insulation class: F | Gasoline Generator: Phase: single phase or three phase Frequency: 50Hz. or 60Hz. AC Max. output(Kw): 8.0 Rated output voltage(V) AC 110; 120; 110/220; 120/240; 220/380; 230/400; 240/415（customized）. Power factor: 1.0(50Hz.) Engine model: KT192F(e) Max. output(HP): 15 Displacement(CC): 460 Petrol engine type: SINGLE-cylinder, forced air-cooling. 4 stroke OHV Compression ratio: 8.3:1 Starting System: Electric starting/RECOIL Lubricatuin system: Forced lubrication Fuel tank(L): 15 Machine oil capacity(L): 1.1 Noise lavel(Db/7M): 68 Packing size(MM): 720x 560x 720 Net weight(Kg): 98 Gross weight（Kgs）106 |
